The robust Titan weighbridge has a fully welded drive-through steel structure, designed to withstand very high concentrated loads and continual use, making it ideal for harsh working environments in steel manufacture, quarrying, mining, construction sites, ports and terminals.
The varying concentration of lateral steel beams along the length of the weighbridge deck takes into account high loading areas and the over-sized longitudinal beams are specified for minimum of 6 metre deflection along the maximum 30 metre length. A range of bespoke capacities, lengths and widths is available to order.
The Titan is also suitable for short term portable applications where the use of special load cell mount assemblies and steel ramps provide a low-profile solution for temporary installations.
These robust weighbridges are all SABS approved loadcells with built-in lightning protection
Loadcells are ball and cup type which allow for total self-alignment
SABS approved weighbridge indicator with RS-232 output
Concrete approaches are completely chip and crack proof
Side and movement stops are a standard fixture on all Titan weighbridges
All required cables and summation card with enclosure
Standalone desktop or laptop
Laser or dot matrix printer
Weighbridge Techniques TITAN vehicle management software
(Newest version available).
Software can also be modified to accommodate client requirements.
Additional devices can be added to the system such as V-cams
that can capture transactions in progress and prevent
theft and other criminal activities.
The TITAN combines the strength and light weight of steel, with a concrete durable steel bridge.
